These files are very useful if you would like to update your cars modules to the latest firmware/coding using BMW Standard tools For the latest on your model, please refer to the update matrix here BMW E65 – SP-DATEN Update files – here.
Here is a guide to show you how correctly connect and set up BMW ENET Cable with BMW ISTA Rheingold software! It is the first step to use this cheap BMW F Series coding cable instead of ICOM!
- BMW INPA Window 7/8 Installation Guide: STEP 1: INSTALLING BMW STANDARD TOOLS. Download and install BST 212. Since BST (BMW Standard Tools) was designed for Win XP 32bit operating Systems, users have faced issues with tools like WinKFP and NCSExpert since Win 7 64bit systems have been introduced. Running in XP compatibility mode just wasn’t.
- (, 02:52 PM) aths Wrote: Dear All, I have installed BMW Standard tools 2.12 successfully. Everything went fine, the environment variables/ paths are set properly. Attached you can fine the EDIABAS.ini located in C: EDIABAS BIN and obd.ini I put in C: EDIABAS BIN and C Windows- in both cases it's the same (not working).
- And if you need download BMW Tool software separately: BMW INPA 6.4.3 software, free download. BMW E-sys 3.30.01 3.29.0 3.28.1 Coding Software Download BMW Standard Tools 2.12 Free Download.
- BMW INPA Software Download Work With INPA Cable. BMW INPA software new update, BMW INPA Cable with BMW INPA Software for BMW E serial programming.here eobdtool.com share full BMW INPA software 5.0.6 download BMW INPA software for F and E series models. BMW INPA Software 5.0.6 do not test, pls try it for INPA cable by your own risk.
Preparations:
And here is a collection about BMW Coding/Programming,check it here:BMW Coding/Programming
Step 1
Connect your laptop/PC with vehicle using the ENET cable.
After that, go to Control Panel→ Network and Internet→ Network Connections.
Select the Ethernet that is connected to the vehicle and open the Properties screen.
Select Internet Protocol Version 4 (TCP / IP) and click the Properties button.
Enter 169.254.1.1 for the IP address and 255.255.0.0 for the subnet mask then press the OK button.
Or if you install ISTA in VMWare, try this way:
Open Virtual Network Editor and disconnect form the host all adapters with Subnet Address 169.254.0.0. Uncheck the box “Connect a host virtual adapter to this network”.
Step 2
Turn on car ignition and run BMW ISTA Rheingold.
Click the Setting button as below:
Select “VCI Config” tab and “HO-ICOM ENET local and ISIS network” option, click the OK button.
Back to main menu and click the Operations button. Select “Read out Vehicle Data” tab and click “Complete Identification”.
Bmw Standard Tools 2.12 Windows 10 Download
Bmw Standard Tools Windows 10 Download
Step 3
Select your ENET connection from the list and click “Set up connection”.
Bmw Standard Tools 2.12 Windows 10
And just wait the vehicle identification process complete!
Or here is another alternative way after you click the Setting button and select “VCI Config” tab:
Choose “HO-ICOM ENET direct connection” option and set ENET mode with empty IP-Address.
That’s all about how to set up BMW ENET cable with BMW ISTA. This guide is tested OK but not responsible for any potential lose or damage!
